OXPCIe200_Datasheet

　　OXPCIe200 Datasheet

　　Part of PLX\‘s Expresso family of high-performance PCI Express® devices， the OXPCIe200 is a single-chip multi-port bridge with a rich set of connectivity ports and advanced system management to maximize data throughput while substantially reducing CPU and system loading.

　　A fully integrated， single-lane PCI Express end-point controller and SerDes enables host system to access the USB 2.0 host， SPI and SRAM ports， a PLX high-performance 950 UART， plus user-defined GPIOs/PWMs. The device operates as either dual USB 2.0 host ports or one USB 2.0 host port and one SPI or SRAM port providing a high-throughput communication path from a PCI Express host system to a slave processor or peripherals.

　　Complete with the Oxide development tools and certified device drivers， the OXPCIe200 is easy to design-in and the ideal connectivity solution for a diverse range of products， including inter-processor communication， device control， I/O expansion， and Multi-modem ExpressCard modules.

　　Accelerate product development and time to market with Oxide and PLX\’s easy-to-design-in， high-performance serial connectivity solutions that just work.
